Mountz EPC-10 Parameter, Monitoring & Process Controller

for EPT-series screwdrivers

The EPC-10 wireless controller operates with only the EPT-Series Transducerized Smart Cordless Screwdrivers. One controller can be used with up to eight (8) screwdrivers.

Mountz EPT transducerized smart cordless screwdriver systems provide engineers and operations with the latest error-proofing technology that eliminates manufacturing risks and prevents product defects. The EPT control system monitors and controls all aspects of the fastening process, from installing error-proofing disciplines to adaptive fastening strategies.

Combined with built-in screw counters and error-proofing software, Mountz DC control tools offer maximum production results and product oversight. The EPT control system monitors and controls all aspects of the automation process, from installing error-proofing disciplines to adaptive fastening strategies.

EPT-Series drivers offer a torque range suitable for low and higher torque applications. All Mountz DC controllers include free product software for programming and analysis – no annual licensing is required.

Key Features

Control screwdrivers remotely
Connect up to 8 (eight) EPT cordless screwdrivers
Front panel 10.1" Color LCD with touch screen
16 Input & 16 Output flexible I/O (25P D-Sub)
Communication 1x RS232C, 1x Ethernet, WiFi
Protocol: Modbus
4.0 MES system ready
Mini SD Card data memory slot (memory card included)
Mounting bracket included
Supports barcode scanner

Process Optimization

Fastening Quality Control: OK/NG monitoring of screw fastening by a preset pattern of angle and/or time.
Fully programmable via the touch screen.
PC-based program for parameter settings, monitoring, and real-time output.
The built-in screw counting function ensures that all screws are accounted for during the assembly process.
Digital I/O allows interfacing with a machine & PLC interface for line control monitoring techniques.
Programmable fastening sequences and workflows. Create standardized fastening workflows.
Program up to 15 presets and 15 models, consisting of up to 20 steps for each model.

Error-Proofing

Job Manager interface makes it easy to create, save and recall visual assembly instructions for an operator to use. Program or verify parameter settings for cordless screwdrivers.
Provide operators with on-screen step-by-step instructions with pictures for up to 15 assembly processes.

Data Collection and Analysis

Data collection – record and store torque and fastening data.
Collect and store essential quality data in a repository for data analytics, regulatory compliance, and traceability.
Provides fastening torque data analysis (Standard Deviation, Mean, Average, Cp, CpK).

Order Code

M313005 = Controller EPC-10
