Mountz EPT Transducerized Smart Cordless Screwdrivers

Torque Ranges 8 ... 212.4 lbf.in

Mountz EPT pistol grip transducerized smart cordless screwdriver systems provide engineers and operations with the latest error-proofing technology that eliminates manufacturing risks and prevents product defects. The EPT control system monitors and controls all aspects of the fastening process, from installing error-proofing disciplines to adaptive fastening strategies.

With a built-in barcode scanner, screw counting function, and error-proofing software, your team can provide operators with the error-proofing and automation capabilities needed to enhance assembly line productivity and decrease production errors and product defects. EPT battery screwdriver operates with the EPC-10 wireless controller. One controller can be used with up to 8 screwdrivers.

EPT-Series drivers offer a torque range suitable for low and higher torque applications. All Mountz DC controllers include free product software for programming and analysis – no annual licensing is required.

Optimize Your Manufacturing Process

The EPT is transducerized – featuring a built-in sensor that continuously measures torque in real-time to collect, record, and store fastening data for analysis.
Using the EPT driver and EPC-10 controllers, engineers can provide operators with on-screen step-by-step instructions for up to 15 assembly processes.
Using a smart tool reduces tooling costs and improves operations by optimizing a company’s manufacturing footprint. A single electric screwdriver fastening system can replace up to 15 screwdrivers.
Mountz EPT screwdrivers are clean room compliant (ISO14644-1 2015 Class 5).

Note: Each screwdriver includes 2 batteries. Charger sold separately. This tool typically ships within 4 - 5 weeks.

Series EPT – Pistol – Hex Drive

Model	Item No.	Hex [inch]	Torque [N·m]	Torque [lbf·in]	Speed [rpm]	Weight [kg]
EPT50100-P	M313131	1/4	0.9 - 4.5	8 - 39.8	100 - 1800	1.7
EPT50120-P	M313133	1/4	1.3 - 6.5	11.5 - 57.5	100 - 1250	1.7
EPT50200-P	M313135	1/4	2.3 - 11.5	20.4 - 101.8	50 - 690	1.7
EPT50300-P	M313137	1/4	3.2 - 16	28.3 - 141.6	50 - 470	1.7
EPT50500-P	M313139	1/4	4.8 - 24	42.5 - 212.4	50 - 310	1.7

Specification according to manufacturer. All information without guarantee, subject to change without notice. Weight with battery.

Series EPT – Pistol – Square Drive

Model	Item No.	SqD [inch]	Torque [N·m]	Torque [lbf·in]	Speed [rpm]	Weight [kg]
EPT50104-P	M313132	3/8	0.9 - 4.5	8 - 39.8	100 - 1800	1.7
EPT50124-P	M313134	3/8	1.3 - 6.5	11.5 - 57.5	100 - 1250	1.7
EPT50204-P	M313136	3/8	2.3 - 11.5	20.4 - 101.8	50 - 690	1.7
EPT50304-P	M313138	3/8	3.2 - 16	28.3 - 141.6	50 - 470	1.7
EPT50504-P	M313140	3/8	4.8 - 24	42.5 - 212.4	50 - 310	1.7

Specification according to manufacturer. All information without guarantee, subject to change without notice. Weight with battery.
