Sturtevant Richmont RFN dovetail head

Common Centre Line 1 7/16 inch (~36.5 mm)

Interchangeable Flare Nut Ratchet Head for Dovetail Torque Wrenches

Single-direction ratchet head with SR dovetail connector. Flare nut is ideal for use with hydraulic or pneumatic fittings.

Key Features

Open ring with 6-point force transmission
Ratcheting in one direction of rotation (not reversible)
Body made from one-piece cast alloy steel
Dovetail connector with outstanding rigidity and wear resistance
Centre Line 1 7/16 inch (~36.5 mm)

The unique SR dovetail design used to join head and wrench provides an exceptionally strong connection and allows complete interchangeability. The SR system contributes to both operational flexibility and enhancing your return on investment!

To achieve constant torque values when changing heads, exact lever length must be maintained. Virtually all SR heads share a precise distance from end of wrench to center of fastener. This is referred to as a “Common Center Line” and is very difficult to maintain using the cut and weld construction method.

Interchangeable heads with the same centre line may be interchanged among themselves arbitrarily, without needing the torque wrench to be adjusted again.

RFN

Model	Item No.	A/F [mm]	max Torque [lbf·in]	max Torque [N·m]	Centre Line [mm]
RFN 10 MM	R 819086	10	400	45	36.5
RFN 11 MM	R 819087	11	400	45	36.5
RFN 12 MM	R 819088	12	400	45	36.5
RFN 13 MM	R 819090	13	400	45	36.5

All specifications without guarantee, errors and omissions excepted.
