Radio Equipped Digital Torque & Angle Screwdriver
The Exacta 1350-TD Digital Torque and Angle Drivers bring a new level of torque control and accuracy to your low torque applications. Here is a quick list of features that help make your low torque applications error-free.
The 1350-TD is compatible with the Global 400 and Global 400mp torque process monitors/controllers. This is a highly versatile torque driver that will make a big impact in your assemblies. Perfect for lower torque applications when you need accuracy and traceability. Up to four tools can operate simultaneously with the Global 400/400mp.
All torque and angle settings are set using the Global 400 or Global 400mp. Error proofing feature: parameters cannot be set using the buttons on the torque screwdriver. This prevents any inadvertent P-Set changes and protects your assembly process integrity. You can pair this tool with multiple P-Sets at different torque or torque and angle values because it is a digital tool. This can be used to replace multiple preset tools.
TAM function (Torque and Angle Monitoring) provides you with "double hit" protection. If a fastener reaches torque without the required degrees of rotation the fastener is rejected as non-compliant. Torque and angle functionality can also alert the operator if a gasket or washer is missing because it shows changing joint conditions.
Green = OK, Red = NOK
The display back light is visible when torque is applied. Displays the torque and angle value on the digital display on the screwdriver. On the 1350-TD the colour of the display on the Global 400 or 400mp corresponds to the light band on tool. Visible from any angle, light band on the driver turns yellow, then green, the screwdriver beeps, and the handle vibrates when target torque is achieved.
The female hexagon version, as well as the male square drive version, gives you the flexibility to meet all of your torque driver application needs. The 1350-TD ships with two NiMH rechargeable batteries. One battery can be charging while the other is in use.
Key Features
Scope of Supply
Options / Accs / Spares
Related Products
| Model | Item No. | Torque Range [cN·m] | Torque Range [lbf·in] | Torque Range [ozf·in] | Torque Range [kgf·cm] | Hex [inch] | Square [inch] | Length [mm] | Weight [kg] |
|---|---|---|---|---|---|---|---|---|---|
| Exacta 1350-TD 100 | R 10772 | 3.5 - 70 | – | 5 - 100 | – | 1/4 | – | 191 | 0.2 |
| Exacta 1350-TD 80 | R 10770 | 45 - 900 | 4 - 80 | – | 4.6 - 92 | 1/4 | – | 191 | 0.2 |
| Exacta 1350-TDM 80 | R 10771 | 45 - 900 | 4 - 80 | – | 4.6 - 92 | – | 1/4 | 191 | 0.2 |
Table showing specifications by the manufacturer. It is recommended to primarily use in medium performance range (approx. 1/3 to 4/5 of rated capacity). If you regularly worked close to the limit of load (maximum capacity), a larger model or tool might be more advisable.
All specifications without guarantee, errors and omissions excepted.
