Sturtevant Richmont 1250 Exacta 2 Digital Torque & Angle Wrench

Capacity 25 / 75 / 150 / 250 / 400 / 600 lbf·ft

Ultimate Flexibility

The 1250 series Exacta 2 Torque and Angle digital torque wrench gives you ultimate control over the most exacting torque specifications. The all new 1250 series Exacta 2 digital torque and angle wrench is built on the same design that has given the 1100 and 1200 series Exacta 2 digital torque wrenches the reputation as the most accurate, reliable and durable digital torque wrenches available.

The 1250 Series brings greater certainty for torque application on your safety critical joints. Using both torque and angle of rotation in different combinations provides greater control over the final torque outcome. Fully compatible with Global 400 and Global 400mp controller where multiple tools with simultaneous uses are needed.

In addition to torque and angle, the new 1250 series Exacta 2 provides additional error proofing by guidance. Programmable wrench display "lighting sequence" works with both torque and angle. Within the engineering specifications, a target can be set to acknowledge target achieved feedback with display colour change and handle vibration when the target torque and angle values are reached.

Robust XBee Pro radio communication speeds support the shortest takt times. Operator can complete active P-Set even if radio communication is severed. When radio communication resumes, the wrench automatically uploads all missed P-Set data.

Five Operational Modes

T2A: Measures torque first and then degrees of fastener rotation to stretch the fastener a predetermined amount. That closely managed bolt stretch creates greater repeatability than using torque alone.
TAM: Measures torque while ensuring sufficient rotation. Helps identify “double-tightened” fasteners and changing joint conditions.
PTM: Factors out friction inherent to lock nuts.
RES: Audit torque value on previously tightened fasteners with greater accuracy.
PEAK: Pure torque measurement without angle measurement.

Features

Bi-directional ± 1% Indicated Value from 20% to 100% of tool capacity.
Meets/exceeds the ASME and ISO standards.
Five modes: Torque to Angle (T2A), Torque with Angle Monitoring (TAM), Residual Torque (RES), Prevailing Torque Mode (PTM), Peak Mode.
Provides digital date/time stamped documentation on every fastening achieved with our wireless tools.
Up to four tools can operate simultaneously with the Global 400/400mp.
Robust radio communication resumes, the wrench automatically uploads all missed P-Set data.
The wrench automatically recalibrates for P-Sets requiring different head lengths.
Available with traditional fixed ratchet, pin/spring dovetail, optional quick change (QC) dovetail with access to well over 200 interchangeable heads.

Scope of Supply

Wrench 1250 Exacta 2
Rugged Plastic Case
2x NiMH Rechargeable Battery Cartridge + 1x Charger
Operating Manual
Traceable Certificate of Calibration (NIST)

Options / Accs / Spares

#10674 = Kit of 2x Battery Pack 3.6V + 1x Charger
#10673 = Battery Pack Charger
#10672 = NiMH Battery Pack 3.6V 2100mAh

Quick Change Dovetail Head (QC)

For those applications where rapid and frequent head size changes are required SR offers the Quick Change heads. The regular dovetail use the pin and spring embedded in the dovetail. The Quick Change dovetail uses a ball bearing and spring which facilitates the use of thumb power. Rather than using a small, flat head screwdriver or our CART tool to depress the pin and remove the head, at customer request SR designed these wrenches to make a head change only using pressure from your thumb.

Everything had a trade off. While the QC style dovetail makes interchangeable head changes very fast, size and torque limitations come into play. We recommend that you use heads of 1 1/4 inches or smaller and 250 ft lbs / 339 Nm is the highest torque level where the QC configuration can be used. Your safety is always our concern.

Related Products

Global 400
Global 400mp
HT

Interchangeable Dovetail Heads

1250 Exacta 2

Model	Item No.	Torque Range [N·m]	Torque Range [lbf·ft]	Torque Range [lbf·in]	Tool tang
1250 Exacta 25	R 10652	6.8 - 34	5 - 25	60 - 300	Dovetail
1250 Exacta 75	R 10653	20 - 101	15 - 75	180 - 900	Dovetail
1250 Exacta 150	R 10654	41 - 203	30 - 150	360 - 1800	Dovetail
1250 Exacta 250	R 10659	68 - 339	50 - 250	600 - 3000	Dovetail
1250 Exacta 400	R 10656	108 - 542	80 - 400	960 - 4800	Dovetail

Note: The lever length on models 25 up to 250 are based on 1 7/16” or 36.5 mm head length. Lever length for the 10656 is based on a 3 7/8” or 98.4 mm head length.

1250 Exacta 2 – Ratchet Head

Model	Item No.	Torque Range [N·m]	Torque Range [lbf·ft]	Torque Range [lbf·in]	SqD [inch]
1250 Exacta 250 R	R 10655	68 - 339	50 - 250	600 - 3000	1/2
1250 Exacta 400 R	R 10671	108 - 542	80 - 400	960 - 4800	3/4
1250 Exacta 600 R	R 10657	163 - 813	120 - 600	1440 - 7200	3/4

816956 = RRK-1/2 Ratchet Renewal Kit
816999 = RRK-3/4 Ratchet Renewal Kit

1250 Exacta 2 – QC

Model	Item No.	Torque Range [N·m]	Torque Range [lbf·ft]	Torque Range [lbf·in]	Tool tang
1250 Exacta 25 QC	R 10666	6.8 - 34	5 - 25	60 - 300	Dovetail QC
1250 Exacta 75 QC	R 10667	20 - 101	15 - 75	180 - 900	Dovetail QC
1250 Exacta 150 QC	R 10668	41 - 203	30 - 150	360 -1800	Dovetail QC
1250 Exacta 250 QC	R 10669	68 - 339	50 - 250	600 - 3000	Dovetail QC

Table showing specifications by the manufacturer. It is recommended to primarily use in medium performance range (approx. 1/3 to 4/5 of rated capacity). If you regularly worked close to the limit of load (maximum capacity), a larger model or tool might be more advisable.

All specifications without guarantee, errors and omissions excepted.
