Crane IQWrench3 Digital Torque & Angle Wrench

Capacity 10 / 25 / 75 / 120 / 180 / 340 / 600 / 750 / 1500 Nm

Advanced digital torque wrench with built-in data collection

The IQWrench3 is the latest in a long line of innovative torque wrenches from Crane. Combining the precision torque and angle measurement capabilities of an advanced torque wrench, along with the storage and reliability of a robust data collector, the IQWrench3 delivers one powerful integrated solution.

The IQWrench3 digital torque wrench delivers all of the expected attributes that made their predecessors such a success, as well as a host of new features.

A colour OLED screen provides clear and easy-to-view results and readings with a straightforward menu system for easy navigation. The LED flashlight and improved 360° light ring make it effortless to reach target torque and effectively manage the fastening process.

Compatible with all typical wrench head adapters including Fixed, DIN and ID heads (Crane’s Auto-ID system can be added to DIN heads), the IQWrench3 can accurately tighten, measure and simultaneously record thousands of critical fastener results, readings and data directly on the wrench.

The IQWrench3 has a large memory capacity for results and job storage, plus an upgraded battery system for overall improved performance and reliability, making it ideal for assembly and quality control applications.

Key Features

Available in ranges from 25 Nm up to 1500 Nm
Advanced software and torque measurement modes including MoveOn, Yield and Re-tighten
Illuminated LED flashlight for increased visibility in darker, confined spaces
Colour OLED screen with simple menu system for easy navigation and viewing readings & data
Increased internal memory for critical data storage
Interchangeable adapter heads & ‘Auto-ID’ for auto length compensation and multiple job use
FOD (Foreign Object Debris) Compliant for use in the Aerospace & Automotive industries
Point-of-load ‘insensitive’ – no incorrect hand position; torque can be applied from any position on the wrench

Specifications

Zero Stability: <±0.02% FSD/°C
Static Accuracy: ±0.25% FSD
Meas. Modes: Track, Peak, Angle, Audit, MoveOn, Yield, Re-Tighten
Data Storage: >3000 jobs and 20,000 readings; 32GB
Connectivity: RF, Bluetooth, WiFi 2.4 / 5 GHz
Battery: User-swappable Li-ion rechargeable
Status indication: buzzer, vibration, 3-colour LED lightring
Operating Environment: Temperature +5°C to +40°C; Humidity 10-75% non-condensing.
Ingress Protection: IP50

Options / Accs / Spares

Auto-ID heads (on request)
Barcode reader (upgrade)
Wireless comms (RF, Wi-Fi, Bluetooth)

Charging cradle
Comms cradle
Power supply (cradle)
Li-ion battery
Desktop battery charger
USB cable (cradle to PC)

IQWrench3 – with Angle

Model	Torque Range [N·m]	Torque Range [lbf·in]	Torque Range [lbf·ft]	Head Insert [mm]	SqD [inch]	Length [mm]	Weight [kg]
IQW3A-0010-CRDARX	2 - 10	17 - 88	–	9×12	–	n.a.	n.a.
IQW3A-0010-CRFARX	2 - 10	17 - 88	–	–	1/4	n.a.	n.a.
IQW3A-0025-CRDARX	5 - 25	44 - 220	–	9×12	–	n.a.	n.a.
IQW3A-0075-CRDARX	15 - 75	133 - 660	–	9×12	–	n.a.	n.a.
IQW3A-0120-CRDARX	24 - 120	212 - 1060	–	14×18	–	n.a.	n.a.
IQW3A-0180-CRDARX	36 - 180	318 - 1590	–	14×18	–	n.a.	n.a.
IQW3A-0250-CRDARX	50 - 250	443 - 2212	37 - 184	14×18	–	n.a.	n.a.
IQW3A-0340-CRDARX	68 - 340	600 - 3000	50 - 250	14×18	–	n.a.	n.a.
IQW3A-0600-CRDARX	120 - 600	–	89 - 442	14×18	–	n.a.	n.a.
IQW3A-0750-CRFARX	150 - 750	–	110 - 553	–	3/4	n.a.	n.a.
IQW3A-1000-CRFARX	200 - 1000	–	148 - 737	–	1	n.a.	n.a.
IQW3A-1500-CRFARX	300 - 1500	–	221 - 1106	–	1	n.a.	n.a.

The table shows the torque ranges specified by manufacturer. Usage in the medium range (approx. 1/3 to 4/5 of rated capacity) is recommended. If you regularly worked close to the load capacity limit, a larger tool may be ergonomically more advantageous.

All technical data without guarantee, errors and omissions excepted.
