TX Plus (IP) bits w 1/4 hex drive E 6.3
Tip profile Torx Plus® (IP)
1/4" hexagon drive DIN 3126 / ISO 1173 – E 6.3
Tough bits are ideal for hard applications where sudden increases in torque can lead to increased stresses in a bit. A hard screw case is when screwing into metal.
E 6.3 – Hexalobular Torx Plus® (IP) – L50
| Model | Item No. | IP # | L [mm] | Ø [mm] | Pk |
|---|---|---|---|---|---|
| IP6-E6.3-50 | 113601 | 6 | 50 | 3 | 10 |
| IP8-E6.3-50 | 113603 | 8 | 50 | 3 | 10 |
| IP9-E6.3-50 | 113605 | 9 | 50 | 3 | 10 |
| IP10-E6.3-50 | 113607 | 10 | 50 | 3 | 10 |
| IP15-E6.3-50 | 113609 | 15 | 50 | 4 | 10 |
| IP20-E6.3-50 | 113611 | 20 | 50 | 4.5 | 10 |
| IP25-E6.3-50 | 113612 | 25 | 50 | 6 | 10 |
| IP30-E6.3-50 | 113615 | 30 | 50 | 6 | 10 |
| IP40-E6.3-50 | 113617 | 40 | 50 | – | 10 |
E 6.3 – Hexalobular Torx Plus® (IP) – L90
| Model | Item No. | IP # | L [mm] | Ø [mm] | Pk |
|---|---|---|---|---|---|
| IP6-E6.3-90 | 113602 | 6 | 90 | 3 | 10 |
| IP8-E6.3-90 | 113604 | 8 | 90 | 3 | 10 |
| IP9-E6.3-90 | 113606 | 9 | 90 | 3 | 10 |
| IP10-E6.3-90 | 113608 | 10 | 90 | 3 | 10 |
| IP15-E6.3-90 | 113610 | 15 | 90 | 4 | 10 |
| IP20-E6.3-90 | 113612 | 20 | 90 | 4.5 | 10 |
| IP25-E6.3-90 | 113614 | 25 | 90 | 6 | 10 |
| IP30-E6.3-90 | 113616 | 30 | 90 | 6 | 10 |
| IP40-E6.3-90 | 113618 | 40 | 90 | – | 10 |
All specifications without guarantee, errors and omissions excepted.
