Tohnichi RNTDZ Insulated Preset Torque Screwdriver

Capacity 260 / 500 cNm

Insulated Rotary Slip Preset Torque Screwdriver

Same basic features and functions as Preset type RNTD but with insulated body. Designed for use in environments where there are potential electric shock hazards. Withstands voltage: Max AC1000V. Prevents electric shock accidents.

Preset style is ideal for applications which requires the same torque value on the line. When set torque value is achieved, rotary slip prevents over-torque. Suitable for work activities that require insulation work. Ideal for electric car assembly, connection of battery terminal, and wiring work.

Compliant with calibration procedures of ISO 6789 Type II Class C. Accepts standard 1/4 hex root shaped bits (sold separately). Bits are not insulated.

Application

Electric motor vehicles, batteries, contamination prevention.

Key Features

Withstands voltage: max AC 1000V
Accuracy acc. EN ISO 6789 type II class D
To be preset by adjusting tool and torque tester (not included)
Clockwise direction
Rotary slip clutch 'Cam-Over' mechanism
Hex bit insert E 6.3 (1/4 inch)

Scope of Supply

Torque Screwdriver RNTDZ
Original user manual (jap./eng.)

RNTDZ

Model	Item No.	Torque Range [cN·m]	Torque Range [lbf·in]	Torque Range [kgf·cm]	OvL [mm]	Weight [kg]
RNTDZ260CN	NEW	100 - 260	9 - 23	10 - 26	126	0.24
RNTDZ500CN	NEW	200 - 500	18 - 44	20 - 51	140	0.34

Table showing specifications by the manufacturer. It is recommended to primarily use in medium performance range (approx. 1/3 to 4/5 of rated capacity). If you regularly worked close to the limit of load (maximum capacity), a larger model or tool might be more advisable.

All technical data without guarantee, errors and omissions excepted.
