Sturtevant Richmont SDR Adjustable Torque Wrench

Capacity 6 / 20 / 50 / 100 / 140 / 200 / 300 / 800 Nm

Ratcheting Square Drive Micrometer Adjustable Clicker Wrench

SR: "Customers tell us they love these wrenches because they are accurate, reliable, and durable. In designing the new handle we kept all the things that our customers love and added the Knurl Grip aluminum handle. Strong, lightweight, rugged, ergonomic, this handle truly lets you get a grip on torque."

In sync with the Sturtevant Richmont approach to customers you can buy just a retrofit kit and replace the handle yourself or you can buy new wrenches with the new handle already in place. Either way the best accuracy, reliability, and durability is within your grasp.

Micrometer Adjustable Ratcheting Square Drive torque wrenches are ideal for any application where:

The fastener or fitting to be tightened can be engaged with a socket,
The user changes from one torque to another often,
A high amount of rotation or limited access requires ratcheting to achieve the desired torque,
The ability to select the torque and lock it in rapidly is needed,
Simplicity of operation is needed,
Very high durability is needed.

These needs are common in small quantity assembly operations and many maintenance functions; the SDR-Series tools are superb for these types of applications.

Key Features

Accuracy of ± 4% of Indicated Value from 20% to 100% of rated capacity.
Meets or exceeds requirements of ASME B107.300-2010 and ISO 6789.
Ratchet design is exceptionally strong and durable.
Fast adjustment – takes the fewest grip rotations of any tool to reach full scale.
Simple thumbscrew mechanism locks to avoid changing torque setting accidentally.
New aluminum knurl grip handle.

Scope of Supply

Torque wrench SDR
Traceable certificate from SR's ISO/IEC 17025 Accredited Calibration Laboratory
Operating manual
All tools of 250 foot-pound (or equivalent) capacity and below come with a custom molded plastic case

Options / Accs / Spares

Old version with neoprene handle optionally convertible to metal handle. Ask for your "Knurl Grip Conversion Kit".
Ratchet Renewal Kits:
816998 = RRK-1/4 w Slide Pin
816958 = RRK-3/8 w Slide Pin
816956 = RRK-1/2 w Slide Pin
816999 = RRK-3/4 w Slide Pin

NATO approval (NSN)

5120-01-394-4271 = 6SDR300
5120-01-394-4273 = 6SDR600
5120-01-394-4289 = 2SDR50I
5120-01-394-4291 = 3SDR200I
5120-01-394-4292 = 2SDR150I
5120-01-394-4293 = 3SDR150I
5120-01-394-4294 = 3SDR750I
5120-01-394-4295 = 3SDR600I
5120-01-394-4296 = 3SDR100
5120-01-394-4297 = 3SDR1200I
5120-01-394-4298 = 4SDR1800I
5120-01-394-4299 = 4SDR150
5120-01-394-4300 = 4SDR250
5120-01-650-4990 = 3SDR75

SDR – Newton-metre

Model	Item No.	Torque Range [N·m]	Graduation	Sq.Drv [inch]	Weight [kg]	Length [mm]	Grip
2 SDR 6 NM MG	R 869774	1.2 - 6	0.1	1/4	0.5	285	MG
2 SDR 20 NM MG	R 869775	4 - 20	0.2	1/4	0.5	295	MG
3 SDR 20 NM MG	R 869776	4 - 20	0.2	3/8	0.5	295	MG
3 SDR 50 NM MG	R 869782	10 - 50	0.5	3/8	0.6	334	MG
3 SDR 100 NM MG	R 869777	20 - 100	0.5	3/8	0.7	380	MG
4 SDR 100 NM MG	R 869797	20 - 100	0.5	1/2	0.7	380	MG
3 SDR 140 NM MG	R 869783	28 - 140	1	3/8	0.8	468	MG
4 SDR 140 NM MG	R 869798	28 - 140	1	1/2	0.8	468	MG
4 SDR 200 NM MG	R 869778	40 - 200	1	1/2	0.9	487	MG
4 SDR 300 NM MG	R 869779	60 - 300	2	1/2	1.6	639	MG
6 SDR 300 NM MG	R 869789	60 - 300	2	3/4	1.6	639	MG
6 SDR 800 NM	R 810598	160 - 800	5	3/4	4.8	989	MG

SDR – Pound-inch

Model	Item No.	Torque Range [lbf·in]	Graduation	Sq.Drv [inch]	Weight ]kg\|	Length [mm]	Grip
2 SDR 50i MG	R 869749	10 - 50	1	1/4	0.5	272	MG
2 SDR 150i MG	R 869750	30 - 150	2	1/4	0.5	285	MG
3 SDR 150i MG	R 869751	30 - 150	2	3/8	0.5	294	MG
2 SDR 200i MG	R 869781	40 - 200	2	1/4	0.5	285	MG
3 SDR 200i MG	R 869761	40 - 200	2	3/8	0.5	298	MG
3 SDR 600i MG	R 869748	120 - 600	5	3/8	0.7	385	MG
3 SDR 750i MG	R 869752	150 - 750	5	3/8	0.7	390	MG
3 SDR 1200i MG	R 869747	240 - 1200	10	3/8	0.8	467	MG
4 SDR 1800i MG	R 869755	360 - 1800	10	1/2	0.9	475	MG

SDR – Pound-foot

Model	Item No.	Torque Range [lbf·ft]	Graduation	Sq.Drv [inch]	Weight [kg]	Length [mm]	Grip
3 SDR 75 MG	R 869756	15 - 75	0.5	3/8	0.7	380	MG
3 SDR 100 MG	R 869754	20 - 100	1	3/8	0.8	468	MG
4 SDR 150 MG	R 869757	75 - 150	1	1/2	0.9	487	MG
4 SDR 250 MG	R 869758	50 - 250	2	1/2	1.6	639	MG
6 SDR 600	R 810597	120 - 600	5	3/4	4.8	984	MG
6 SDR 700	R 810525	140 - 700	5	3/4	7.5	994	MG

Table showing specifications by the manufacturer. It is recommended to primarily use in medium performance range (approx. 1/3 to 4/5 of rated capacity). If you regularly worked close to the limit of load (maximum capacity), a larger model or tool might be more advisable.

MG = Knurled Metal Grip.

All specifications without guarantee, errors and omissions excepted.
